Description

Technical Overview

Engineers integrate these milled polycarbonate wheels into linear guide systems. Specifically, the component functions by mounting directly onto linear profiles to provide a low-compression rolling interface. We individually mill each wheel from clear polycarbonate. Because of this processing, the manufacturing method ensures consistent high precision and tight dimensional tolerances. Consequently, the clear material resists wear and deformation under mechanical forces. Furthermore, the Solid V Xtreme Wheel Kit works interchangeably with compatible plates and parts within compact gantry setups. When you assemble multiple wheels onto a gantry plate, the final configuration distributes structural loads evenly across the system.

Applications

Builders install this Solid V Xtreme Wheel Kit assembly on linear guide tracks, including V-Slot linear systems. In particular, technicians deploy the hardware in the construction of CNC routers and milling machines where operational loads introduce significant weight and force. For this reason, the polycarbonate design serves as an alternative to standard Delrin wheels when applications require minimal material deflection. Meanwhile, experimental testing demonstrates the component withstands a load of 25 lbs per wheel without observable deflection, making it suitable for integration into multi-wheel automated assemblies.

Technical Specifications

Maker Store Tips and Tricks

* Remember to purchase your Spacers and M8 Cap Head Bolts separately to complete the gantry assembly.

• Distribute the system load evenly by utilizing multiple wheels across your gantry plate configuration.

• Avoid over-tightening the nylon insert lock nut to prevent excessive bearing preload and ensure unhindered rotation.
