Description
Technical Overview
Operators deploy this multi-function hand tool to perform wire stripping, terminal crimping, cable cutting, and clamping within electrical assemblies. Specifically, the unit combines four distinct manual functions into a single jaw assembly. For instance, the stripping mechanism handles 10 to 20 AWG (American Wire Gauge) solid and stranded conductors. Meanwhile, the crimping profile accommodates 10 to 22 AWG insulated and uninsulated terminals. In addition, an integrated cutting edge processes copper, aluminium, and sheathed core conductors.
Furthermore, manufacturers construct the Multi-Function Hand Tool with thermoplastic rubber (TPR) handle grips and a concealed internal return spring. Consequently, this spring provides mechanical assistance to reduce handle reset force during repetitive operational cycles. Additionally, an integrated manual safety latch locks the jaw mechanism in the closed position during storage. As a result, this latch effectively protects the sharp cutting and stripping edges from damage.
Applications
Technicians utilize this Multi-Function Hand Tool across electrical panel fabrication, control cabinet wiring, and general industrial maintenance. For example, during wiring harness construction, the tool enables single-tool execution of wire cutting, insulation stripping, and terminal crimping without swapping hand tools between steps.
Specifically, workers use the tool to prepare 10–20 AWG power and control conductors, strip outer jacket insulation, and secure crimp terminals onto 10–22 AWG wire ends. Moreover, the clamping functionality actively assists operators in positioning, bending, and holding lead wires prior to terminal insertion or soldering operations.
Technical Specifications
Maker Store Tips and Tricks
-
Do not use the cutting jaws on hard metals, alloy steel, or stainless steel wire to prevent dulling or fracturing the blade edges.
-
Verify conductor thickness is within 10 to 20 AWG prior to stripping to prevent damaging internal copper strands.
-
Engage the manual safety lock when storing the tool to prevent accidental blade exposure.
