Description
These all-metal geared 775 DC Motors offer high torque and speed. These DC Motors are great for robotics projects or for use in actuators.
Available in different speed and voltage configurations, these motors will offer a robust solution for any automation project.
Specifications:
Shaft Diameter: 8mm
12V Motors:
| Description | SKU | RPM | *Rated Current (Amps) | *Rated Torque (Kg/cm) |
| 12V, 30 RPM Geared Motor | ELEC-DCGM-12V30 | 30 | 1.95 | 23 |
| 12V, 110 RPM Geared Motor | ELEC-DCGM-12V110 | 110 | 2.38 | 13 |
| 12V, 360 RPM Geared Motor | ELEC-DCGM-12V360 | 360 | 2.385 | 4.8 |
| 12V, 630 RPM Geared Motor | ELEC-DCGM-12V630 | 630 | 2.4 | 3.2 |
24V Motors:
| Description | SKU | RPM | *Rated Current (Amps) | *Rated Torque (Kg/cm) |
| 24V, 30 RPM Geared Motor | ELEC-DCGM-24V30 | 30 | 1.2 | 25 |
| 24V, 110 RPM Geared Motor | ELEC-DCGM-24V110 | 110 | 1.5 | 14 |
| 24V, 360 RPM Geared Motor | ELEC-DCGM-24V360 | 360 | 1.458 | 5 |
| 24V, 630 RPM Geared Motor | ELEC-DCGM-24V630 | 630 | 1.5 | 3.5 |
*Please Note:
The above torque and current values are approximate values. Factors such as wiring, power supply, load and control methods may affect torque and current consumption.
