Nema 17 Stepper Motor 560mN.m – Version B

$26.20 Inc. GST

The Maker Store NEMA17 stepper motor is a great choice for any project. It comes with a 1m lead with a 4-pin Dupont style connector – perfect for connecting to breadboards or circuit boards!



In stock

LCN: E-04-V / I-02-V SKU: ELEC-NEMA17-B Category: Tags: , , , , ,

Description



The Maker Store NEMA17 stepper motor is a great choice for any project. It comes with a 1m lead with a 4-pin Dupont style connector – perfect for connecting to breadboards or circuit boards!

With an all black body, these motors also look fantastic!

Specifications

  • Step Angle:1.8°
  • Number of Phase: 2
  • Rated current (single phase):1.7 A DC
  • Rated Voltage: 3.06V
  • Winding dc resistance(25℃):1.8Ω±10%
  • Winding inductance:3.8mH±20%
  • Holding torque:≥560mN.m(I=1.7A)
  • Shaft diamater: 5mm

Motor Data Sheet:

Click HERE to Download Datasheet

Additional information

Weight .36 kg
Dimensions 7 × 4.2 × 4.2 cm
