Description
Technical Overview
The Panel Mounting Bracket for 20 Series operates as an aluminium extrusion accessory that provides secure mounting paths for panels and displays. This hardware component mounts directly onto standard 20 Series aluminium extrusion profiles. Consequently, operators can efficiently insert and fasten structural panels, electronics, or protective sheets directly into the bracket slot to build rigid, integrated frame structures.
Applications
Engineers specifically deploy this aluminium bracket in commercial, industrial, and residential environments where assemblies require robust and reliable panel integration. Because the component fastens directly to structural profiles, it creates a stable, durable mounting surface for heavy-use interfaces.
Typical applications include the following configurations:
-
Industrial Controls: The bracket safely secures industrial control panels, touchscreens, and control monitors.
-
Enclosures: It supports the installation of protective paneling within machine enclosures and safety cages.
-
Displays: Finally, it structurally stabilizes retail displays, hardware housings, and electronic equipment enclosures.
Maker Store Tips and Tricks
-
Slide the bracket into the profile channel and loosely position it before inserting the panel to simplify structural alignment.
-
Use standard M5 low-profile or button head screws to ensure flush seating within the bracket thread and clear panel clearance.
-
Periodically verify thread tension in high-vibration machinery environments to maintain a rigid hold on delicate electronic displays.
Specifications:
- Material: Cast aluminium
- Thread: M5
Unsure which products are compatible with our aluminium extrusions?
Look for the Maker Store Compatibility Badges!
