Description

Please Note:

These are available in colours Black, Red/Green and Green. If you would like a certain colour please contact us so that we can assist you.

These special edition High Quality MGN7C Linear Bearings are a tiny and lightweight rail slide block, suitable for miniature equipment. Used in 3D Printing, CNC Machining, Robotics, Measuring Equipment and Other Machinery. Along with the MGN7 Rail this block offers high rigidity and precision accuracy.

Specifications:

All metallic components of the Block and Rolling Balls made from chrome steel
Arch contact design offers high rigidity and precision accuracy
Steel Balls held captive by a retainer
Sustains loads from all directions
Uses a Rolling Circulation System
Colours: Green, Black, Red/Green

Notes:

Leave the Block Support Rail that comes with the packaging in the block until installation to avoid the Steel Balls from escaping the retainer. When installing the block onto the rail, use the rail to push the Support Rail out of the block, this ensures the Steel Balls are under tension and have contact with a rail at all times.
Over Tightening of Rail Mounting Bolts will seriously affect the accuracy and function of the Block.
